0603series
Download Item P/N Color Size (mm) Wp(nm) Ie(mW/sr) Φe (mW) IF (mA) Degree
1 AP0603A-YHR-020mA IR Series 1.6*0.8*0.5 840~860 1.0~2.0 mW/sr 20 130
2 SP0603A-IRH-020mA IR Series 1.6*0.8*0.5 860~900 1.0~2.0 mW/sr 20 130
3 AP0603F-YIR-050mA IR Series 1.6*0.8*0.95 830~860 10~55 mW/sr 50 45
4 AP0603F-ZIR-050mA IR Series 1.6*0.8*0.95 930~960 10~55 mW/sr 50 45
5 AP0603A-ZVD-015mA VCSEL 1.6*0.8*0.5 930~950 5~20mW 15 25
Download Item P/N Color Size (mm) Wp(nm) Ie(mW/sr) Φe (mW) IF (mA) Degree
1 AP0603A-YHR-020mA IR Series 1.6*0.8*0.5 840~860 1.0~2.0 mW/sr 20 130
2 SP0603A-IRH-020mA IR Series 1.6*0.8*0.5 860~900 1.0~2.0 mW/sr 20 130
3 AP0603F-YIR-050mA IR Series 1.6*0.8*0.95 830~860 10~55 mW/sr 50 45
4 AP0603F-ZIR-050mA IR Series 1.6*0.8*0.95 930~960 10~55 mW/sr 50 45
5 AP0603A-ZVD-015mA VCSEL 1.6*0.8*0.5 930~950 5~20mW 15 25
0805series
Download Item P/N Color Size (mm) Wp(nm) Ie(mW/sr) Φe (mW) IF (mA) Degree
1 AP0805A-ZIR-020mA IR Series 1.25*2.0*0.8 930~950 0.57~1 mW/sr 20 120
Download Item P/N Color Size (mm) Wp(nm) Ie(mW/sr) Φe (mW) IF (mA) Degree
1 AP0805A-ZIR-020mA IR Series 1.25*2.0*0.8 930~950 0.57~1 mW/sr 20 120
3010(IR series)
Download Item P/N Color Size (mm) Wp(nm) Ie(mW/sr) Φe (mW) IF (mA) Degree
1 BL3010A-ZIR IR Series 3.0*1.0*2.0 930~950 typ:0.8 mW/sr 20 150
Download Item P/N Color Size (mm) Wp(nm) Ie(mW/sr) Φe (mW) IF (mA) Degree
1 BL3010A-ZIR IR Series 3.0*1.0*2.0 930~950 typ:0.8 mW/sr 20 150
3010(PD series)
Download Item P/N Color Size (mm) Wp(nm) Range of Spectral Bandwid (nm) IF (mA) Degree
1 BL3010A-ZPD PD Series 3.0*1.0*2.0 typ:940 760~1150 10 -
Download Item P/N Color Size (mm) Wp(nm) Range of Spectral Bandwid (nm) IF (mA) Degree
1 BL3010A-ZPD PD Series 3.0*1.0*2.0 typ:940 760~1150 10 -
